Bush Hog 1812
1812 Flex-Wing Rotary Cutters 1812
Overview:
The 1812 Flex-Wing Rotary Cutter is designed for small tractors with a PTO horsepower of 50 to 75. The narrow cutting width of 12-feet makes this Flex-Wing ideal for rolling terrain where a wide rigid cutter will not perform as well. Grass, weeds, and brush up to 1 1/2-inch diameter are no match for the hardened parall... + Read More
Features
Performance Features
- E-Z clean smooth decks are on the center and wings.
- Wing “free float” without movement of wing hydraulic cylinder rod extends cylinder life.
- Gearbox oil sight gauge allows the checking of the oil level in a few seconds.
- PTO driveline holder is standard.
- Wheel spindles are in halves for economy and ease of maintenance.
- A single hydraulic hose is standard for lifting. Two hoses are optional for lifting wings independently of center section.
Construction Features
- Center section cushions are at each axle arm to absorb shocks near the wheels.
- Replaceable full length sideband skids give maximum protection and strength to the sideband.
- Wheel hub cap retainers are standard to prevent loss of cap and hub grease.
Safety Features
- Safety lights for highway travel are standard.
Product Features
- Full Length Sideband Skids
- Each axle arm on the center section has a rubber cushion to absorb the shock loads near the wheels. Shown with optional dual tires on the center.
- Patented oil sight gauge in all three cutting gearboxes for quick and easy monitoring of oil levels.
Specifications
| Model | 1812 |
| Cutting Width: | 12 ft. |
| Cutting Height: | 2-inches to 12-inches |
| Hitch: | Cast Clevis |
| Tongue Weight: | 1,086 lbs. |
| Estimated Total Weight: | 3,278 lbs. |
| Tractor h.p. Range@ PTO: | 50 to 75 |
| Side Band: | 1/4 in. x 10 in. |
| Blades: | 1/2 in. x 3 in. Hi-Uplift |
| Blade Holder: | Oval Pan |
| PTO Drivelines: | ASAE Cat 4 |
| Center & Wing Drivelines: | ASAE Cat 3 |
| Wing Flex: | 22° Down to 87° up |
| Wing Free Float: | 22° down to 25° up |
| Splitter Gearbox Rating: | 160 h.p. |
| Cutting Gearbox Rating: | 65 h.p. |
| Gearbox Oil Sight Gauge: | Standard |
| Gearbox Warranty: | 5 Years |
| Blade Tip Speed @ 540 pto: | 14,464 FPM Center/13,930 Wings |
| Cutting Capacity: | 1 1/2 in. |
| Decks: | 10 GA. |
| Axle Pivot Points: | Bushings With Grease Fittings |
| Axle Cushions, Center Section: | Rubber Bumper Near Each Wheel |
| Wing Adjustments: | Turnbuckle |
| Safety Tow Chain: | Standard |
| Highway Safety Lights: | Standard |
