Construction Attachments Inc. Severe Xtreme Duty Low Profile Bucket 4-IN-1 Multi-Purpose Attachment
Multi-Purpose Buckets Severe Xtreme Duty Low Profile Bucket 4-IN-1 Multi-Purpose Attachment
Overview:
Severe Xtreme Duty Low Profile Bucket 4-IN-1 Multi-Purpose Attachment is designed for rubber tire and rubber track host machines up to 130 horsepower. This bucket is available in 67", 73", 76", 80" and 84" with the following options: bolt-on large teeth, weld-on teeth, bolt-on cutting edge, bolt-on tooth bar and extended tooth bar.
Features
SEVERE XTREME DUTY LOW PROFILE 4-IN-1 MULTI-PURPOSE BUCKET
Product Features:
- For rubber tire or rubber track host machines up to 130 horsepower, and tractor loaders
- Low profile for improved load visibility
- Radius moldboard for improved material loading and unloading
- Pre-drilled 6” x ¾” front cutting edge to accommodate all bolt-on options
- Solid 6” x ¾” edge is attached to buckets with weld-on teeth
- Reversible bolt-on edge standard for dozer section
- Models include 67”, 73”, 76”, 80” and 84”
Front edge options:
- Bolt-on Large Teeth
- Weld-on Teeth
- Reversible Bolt-on Cutting Edge
- Bolt-on Tooth Bar
- Bolt-on Extended Tooth Bar
Specifications
| Model | 1MPSXD |
|---|---|
| Item | 1MPSXD67 1MPSXD67LT 1MPSXD67WT 1MPSXD67E 1MPSXD67TB 1MPSXD67ETB 1MPSXD73 1MPSXD73LT 1MPSXD73WT 1MPSXD73E 1MPSXD73TB 1MPSXD73ETB 1MPSXD76 1MPSXD76LT 1MPSXD76WT 1MPSXD76E 1MPSXD76TB 1MPSXD76ETB 1MPSXD80 1MPSXD80LT 1MPSXD80WT 1MPSXD80E 1MPSXD80TB 1MPSXD80ETB |
| Item Cont. | 1MPSXD84 1MPSXD84LT 1MPSXD84WT 1MPSXD84E 1MPSXD84TB 1MPSXD84ETB |
| Product Category | 4-IN-1 Multi-Purpose Buckets |
| Duty Rating | Severe Xtreme Duty |
| Product Type | Low Profile |
| Width (Inches) | 67, 73, 76, 80, 84 |
| Attachment Options | Bolt-on Edge (E), Bolt-on Extended Tooth Bar (ETB), Bolt-on Large Teeth (LT), Bolt-on Tooth Bar (TB), Weld-on Teeth (WT), None |
| # of Teeth | 0-9 |
| Heaped Capacity - Cu Ft | 13.86 (67"), 15.22 (73"), 15.88 (76"), 16.75 (80"), 14.64 (84") |
| Max Clam Opening (IN) | 40.25 |
| Weight (LBS) | 881-1152 |
| OEM Colors Available | Yes |
| Designed For Use | scraping, loading, digging, back filling, clam loading, bull dozing, clamping, bottom dumping |
| Suitable For | Rubber Track Host Machine, Rubber Tire Host Machine, Tractor Loaders |
