Land Pride SC7072
SC70 Skid Cutter SC7072
Overview:
Farmers/ranchers, developers, contractors, and rental yards
can clear land or small trees, shrubs, bushes and grass.
Features
| Case drain (optional) | Protects hydraulic motor and seals. |
| Front and rear chain guards | Chain guards on the front and rear of deck. Reduces flying debris. |
| Replaceable skid shoes | Protect side plate structure. Shoes are replaceable for convenience. |
| 3/4" x 7-1/2" free-swinging blades | Free-swinging blades protect from obstructions. |
| 7" cutting capacity | Easily cuts brushy areas & trees up to 7" in diameter |
| Carbide teeth (standard) | Grind down tree stumps |
| Push Bar | Pushes cut trees away from the operator cab. |
| Motor pressure gauge (optional) | Allows the operator to slow down to prevent stalling. |
| Bi-Folding door | Door will fold open when cutting heavy brush and trees. Covers the cutting chamber when not cutting in heavy brush. |
| Height adjustment safety chain | Provides additional operator protection from flying objects by allowing the Skid Cutter to only be lifted up to 18". |
| 1/4" thick deck | Heavy deck design holds up to harsh conditions. |
| Heavy blade carrier | Provides inertia & strength for cuting trees and grinding stumps. |
| Surpassed rugged industry standards | All Kubota Cutters have been designed and tested to meet rigorous voluntary testing procedures according to ISO 4254-13. |
| Polycarbonate door (optional) | Protects operator from thrown objects. |
| 1/4" side panels | Reduces debris piercing possibilities. Can be replaced if damaged. |
| Beveled skid shoes on wings | Reduces gouging the ground when turning. |
Specifications
| Model Number | SC7072 |
| Cutter weight with skid shoes | 2580lbs. |
| Hitch | Welded on |
| Cutting width | 73-1/2" |
| Overall width | 84-3/8" |
| Overall length | 92-1/4" |
| Cutting height | 1 1/2" to 18" infinitely variable. |
| Cutting capacity | 7" Diameter |
| Spindle hub oil capacity | 85 oz. |
| Spindle hub oil | EP 80-90 wt. gearlube |
| High volume drive motor | 26-43 gpm flow |
| Hydraulic pressure | Up to 3500 psi. |
| Deck thickness | 1/4" |
| Side skirt construction | 1/4" Steel |
| Deck wear protection | Four, corner-mounted skid shoes |
| Skid shoe construction | 3/8" plate |
| Blade Carrier | (2) Round 1/2" plate weldments |
| Blade size | 3/4" double edge |
| Blade rotation | Clockwise |
| Blade bolt | 3/4-10 Grade 8 |
| blade tip speed | 11,870 fpm at 43 gpm |
| Front deck protection | Bi-fold door with single row chain guard |
| Rear deck protection | Single row chain guard |
| Deck lift height protection | Height adjustment safety chain |
| Mulching teeth | 3/4" SQ carbide |
